Monorails



Handling Systems offers a wide variety of straight and curved ceiling and floor mounted monorail systems. Ceiling mounted systems are available with drop or flush mount hangers. Floor mounted systems are available in both ‘A’ frame and ‘H’ frame supports. With the expertise to engineer and design, Handling Systems is capable of manufacturing most any custom built free standing monorail system to accommodate a variety of applications.



Handling Systems offers both ‘A’ frame style monorail supports (floor mounted

gantry style) or ‘H’ frame straddle leg supports. ‘H’ frame support structure allows for support column placement free of machinery and forklift traffic.



A monorail system consists of a single straight or curved I beam supported at each end (middle supports may be necessary depending on size) with a trolley and hoist to travel back and forth for material handling. Monorail systems are used to aid in material handling were x,y,z movement like that in a bridge crane is not needed. Most commonly used over a row of machines, in hallways or passages, through paint booths, or to assist in truck loading. Monorail systems are available with festooning packages to keep the air hose or power cord out of the way of the load and user.
